LY-8312 High Resolution (0.1um) Film Thickness Tester with Mechanical Contact Measurement and Automatic Measurement Mode

Brand Name : LIYI

Place of Origin : Guangdong, China

MOQ : 1

Power : 75W

Voltage : 220 V, 380 V, 240 V, 110 V

Weight : 32KG

Resolution ratio : 0.1um

Sampling step : 0 ~ 1000 mm

Injection speed : 0.1 ~ 99.9 mm/s

Machine size : 461mm*334mm*357mm (L*W*H)

Measuring range : 0-2mm

Measuring speed : 10times/min

Measuring pressure : 17.5±1kPa(film);100±1kPa(paper)

Contact area : 50mm²(film),200mm²(paper)

Power supply : 220V 50Hz

Measuring method : Mechanical contact

Display type : LCD

Interface : Standard USB

Contact Now

LY-8312 Film Measurement Plastic Thickness Tester Of Paper
Product Description
The thickness gauge adopts the mechanical contact measurement method, which strictly meets the requirements of the standard and effectively ensures the standardization and accuracy of the test. It is suitable for accurate thickness measurement of plastic film, sheet, diaphragm, paper, foil, silicon and other materials within the range. Characteristics: 1.The contact area and measuring pressure are designed in strict accordance with the standard, and various non-standard customization are supported at the same time; 2.During the test, the measuring head rises and falls automatically, which effectively avoids the system error caused by human factors; 3.Support automatic and manual measurement mode, convenient for users to choose freely; 4.The system automatically injects samples, and the relevant parameters such as injection step, measurement points and injection speed can be set by users themselves; 5.Real time display of analysis data such as maximum, minimum, average and standard deviation of measurement results, which is convenient for users to judge; 6.The standard gauge block is configured for system calibration to ensure the accuracy and data consistency of the test; 7.The system supports many practical functions, such as real-time data display, automatic statistics and printing, to obtain test results conveniently and quickly; 8.The system is controlled by microcomputer, equipped with LCD, menu interface and PVC operation panel, which is convenient for users to conduct test operation and view data; 9.The standard USB interface is convenient for the external connection and data exchange between the system and the computer.
Specifications
Measuring range
0-2mm (Other ranges can be customized)
Resolution ratio
0.1um
Measuring speed
10times/min(adjustable)
Measuring pressure
17.5±1kPa(film);100±1kPa(paper)
Contact area
50mm²(film),200mm²(paper)Note: Film and paper are optional.
Sampling step moment
0 ~ 1000 mm
Injection speed
0.1 ~ 99.9 mm/s
Machine size
461mm×334mm×357mm (L*W*H)
Weight
32Kg
Products Detail
LY-8312 High Resolution (0.1um) Film Thickness Tester with Mechanical Contact Measurement and Automatic Measurement Mode
LY-8312 High Resolution (0.1um) Film Thickness Tester with Mechanical Contact Measurement and Automatic Measurement Mode
Other Options
Company Profile
Dongguan Liyi Environmental Technology Co., Ltd is a high technology supported production-oriented enterprise who specializes in developing, manufacturing, marketing all kinds of environmental equipment. Our company has advanced technology, experienced technical management personnel and efficient professional service staffs, fine quality management and perfect after-sales service system.

Our company mainly produce simulated environmental tester, plastic and rubber tester etc. on all kinds of materials testing industries. The production base is located in the country’s manufacturing center Dongguan, Guangdong province, China. In order to service our customers better in terms of reducing costs and early delivery, in 2005 we had set up an office in Kunshan, Jiangsu province for Eastern China marketing and servicing.

Liyi deals with customers from more than 150 countries and regions. Meanwhile, we are committed to cooperate with different dealers in different countries and regions in order to offer better service. Our mission is to help every customers establish testing labs to ensure the quality of their products.

Our company will continue to develop, innovate and keep faith. We combine with the international testing standards and the specific demands of customers that may establish a new banner in Chinese testing industry.
LY-8312 High Resolution (0.1um) Film Thickness Tester with Mechanical Contact Measurement and Automatic Measurement Mode
FAQ
1. Are you Manufacturer?Do you offer after-sales service? How can I ask for that? And how about the warranty?
Yes, we are the one of professional and biggest Manufacturer like Environmental Chambers, Industrial Ovens, Universal Tensile Testers, UV Aging Test Chambers, Industrial Muffle Furnaces, Paper Packing Testers, Plastic Rubber Testers, Adhesive testers and other testing Equipment.. in China .Every machines purchasing from our factory has 12 months warranty after shipment. Generally, we offer 12 months for the FREE maintenance. while considering of sea transportation,we can extend 2 months for our customers.

Moreover, If your machine doesn’t work, you can send us an E-mail or call us we will try our best to find the problem through our conversation or by video chat if neccesary. Once we have confirmed the problem, the solution will be offered within 24 to 48 hours.

2. What’s the delivery term?
For our standard machine which means normal machines, we have stock in the warehouse. If there is no stock, normally, the delivery time is 15-20 working days after deposit receipt ( this is only for our standard machines) If you are in urgent need, we will making a special arrangement for you.

3. Do you accept customization service? Can I have my logo on the machine?
Yes, of course. We can not only offer standard machines, but also customized machines according to your requirements. And we can also put your logo on the machine which means we offer OEM and ODM service.

4.How can I install and use the machine?
Once you have ordered the testing machines from us, we will send you the operation video in English version through Email.
Most of our machine is shipped with a whole part, which means it is already installed, you just need to connect the power cable and start to use. And if it's necessary, we can also assist you to install your machine on site.
LY-8312 High Resolution (0.1um) Film Thickness Tester with Mechanical Contact Measurement and Automatic Measurement Mode
